Description et caractéristiques
Portier Vidéo IP autonome-
- Caméra à 107 ° en 1 Mpxls
- Lecteur de Badge
- IP65
- POE
- Fonction d'interphone Vidéo
- Pilotage de 2 verrous
Fiche technique
| Processeur | Embedded Processor |
|---|---|
| Système d'exploitation | Embedded Linux OS |
| Button Type | Mechanical |
| Number of Buttons | 1 |
| Interopérabilité | ONVIF; CGI |
| Protocoles réseau | IPv4; RTSP; UDP; DNS; P2P; RTP; TCP; SIP |
| Camera | 1/2.8" 2 MP CMOS high definition, low illumination/DWDR/ color/IR |
| Champ de vision | H: 107°; V: 60°; D: 122° |
| Réduction du bruit | 3D NR |
| Compression vidéo | H.264; H.265 |
| Video Resolution | Main stream: 720p, WVGA, D1, CIF Sub stream: 1080p, WVGA, D1, QVGA, CIF |
| Fréquence d'images | PAL: 25 fps; NTSC: 30 fps |
| Débit vidéo | 256 Kbps–8 Mbps |
| Light Compensation | Auto IR |
| Jour/Nuit | Auto(ICR)/Color/B/W;Color/B/W |
| Compression audio | G.711a; G.711u; PCM |
| Entrée audio | 1 |
| Sortie audio | Built-in speaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression/digital noise reduction |
| Audio Bit Rate | 16 KHz, 16 bit |
| Communication Mode | Full digital |
| Unlock Mode | Card; app; indoor monitor |
| Card Type | IC card |
| Leave Videos | Yes (an SD card must be inserted in the VTH) |
| Web Configuration | Yes |
| Card Reading Distance | 0 cm–4.5 cm (0"–1.77") |
| Issue Card Locally | Yes |
| Matériau du boîtier | PC + Acrylic |
| Card Capacity | 10000 |
| RS-485 | 1 |
| Power Output | 1 port, 12 V and 200 mA |
| Exit Button | 1 |
| Door Status Detection | 1 |
| Lock Control | 1 port, normally closed by default |
| Port réseau | 1 × 10/100 Mbps network port (8-core white ribbon cable) |
| Tamper Alarm | Yes |
| Appearance Color | Black |
| Alimentation | 12 VDC, 1 A Standard PoE |
| Power Adapter | Optional |
| Installation | Surface Mount |
| Certifications | CE |
| Accessory | Included: Alarm power ribbon cable, rain cover, brackets |
| Dimensions | 135.1mm × 70.6mm × 34.6mm (5.32" × 2.78" × 1.36") |
| Indice de protection | IP65 (silicone sealant is needed, see the quick start guide.) IK04 (for common use) |
| Température de fonctionnement | –30 °C to +60 °C (–22 °F to +140°F) |
| Humidité de fonctionnement | 10%–90% (RH), non-condensing |
| Operating Environment | Outdoor |
| Operating Altitude | Beneath 3000 m (9842.52 ft) |
| Consommation | ≤ 1 W (standby), ≤ 5 W (working) |
| Poids brut | 326 g (0.72 lb) |
| Niveau anticorrosion | Basic Protection |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : VTO2111D-P-S2 · Marque : Dahua
