Description et caractéristiques
Moniteur d'intérieur IP
- 2 fils
- Écran tactile 7 pouces
- Noir
- Entrée d'alarme 6 canaux/Sortie d'alarme 1 canal
- 1024x600
Caractéristiques principales
- Type de moniteur : Ecran
- Technologie de moniteur : Moniteur IP, Moniteur 2 fils
- Taille de l'écran : Écran 7 pouces
- Alimentation : Alimentation POE
- Couleur : Moniteur noir
Fiche technique
| Processeur | Embedded processor |
|---|---|
| Système d'exploitation | Embedded Linux operating system |
| Interopérabilité | ONVIF |
| Protocoles réseau | SIP; IPv4; RTSP; RTP; TCP; UDP |
| Screen Type | Capacitive touch screen |
| Écran | 7" TFT |
| Screen Resolution | 1024 × 600 |
| Compression audio | G.711a; G.711Mu; G.711u; PCM |
| Entrée audio | 1 |
| Sortie audio | Built-in speaker |
| Audio Mode | Two-way audio |
| Audio Enhancement | Echo suppression |
| Audio Bit Rate | 16 KHz, 16Bit |
| Communication Mode | Full digital 2-wire |
| Information Release | Receive and view text information released by the management center (After SD card is installed, picture information can be received and viewed.) |
| Leave Videos | Yes (insert an SD card into the indoor monitor) |
| DND Mode | DND period and DND mode can be set. |
| Number of Extension | Villa: 3; apartment: 3 |
| Stockage | Micro SD card (up to 64 GB) |
| Casing | PC + ABS |
| RS-485 | 1 |
| Entrée d'alarme | 6 |
| Sortie d'alarme | 1 |
| Power Output | 1 (12V/100mA) |
| Door Bell | Yes (use any alarm input port) |
| Network | One two-wire port and one 10Mbps/100Mbps Ethernet port (one of them can be selected) |
| Color | Black or white |
| Alimentation | Two-wire switch (max power transmission distance: 100 m); Standard PoE |
| Power Adapter | Not included |
| Installation | Surface mount |
| Certifications | CE; FCC; UL |
| Accessory | Bracket and alarm ribbon cable (included) |
| Dimensions | 189.0 mm × 130.0 mm × 26.9 mm (7.44" × 5.12" × 1.06") |
| Température de fonctionnement | -10°C to +55°C (+14°F to 131°F) |
| Humidité de fonctionnement | 20% to 93% (non-condensing) |
| Operating Altitude | Beneath 3000 m (9842.52 ft) |
| Consommation | Standby ≤ 2W; working ≤ 6W |
| Poids net | 388 g (0.86 lb) |
| Poids brut | 741 g (1.63 lb) |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : VTH5422HB · Marque : Dahua
