Description et caractéristiques
Enregistreur intelligent 1U
- 16 canaux
- WizMind
- 96 Mbps
- AcuPick
- Détection de visage
- Reconnaissance faciale
- Lecture de plaque
- 1 baie HDD jusqu’à 20 To
- 1 HDMI / 1 VGA
- Audio 1 canal
- 4 entrées / 2 sorties alarme
- USB 2.0/3.0
- ONVIF
- Linux embarqué
Caractéristiques principales
- Technologie d'enregistreur : NVR - Enregistreurs IP
- Nombre de voies vidéo : 16 voies
- IA de l'enregistreur : AcuPick, WizMind, Détection de visage, Reconnaissance faciale
- IA supporté par l'enregistreur : Détection de visage, Lecture de plaque, Reconnaissance faciale
- Résolution maximum : 16 MP
Fiche technique
| Processeur | 64-bit high-performance multi-core processor |
|---|---|
| Système d'exploitation | Embedded Linux |
| Operating Interface | Webpage (PCAPP);Local GUI |
| AI Card | 1, AI card mode is switchable |
| AI by Camera | Face detection; face recognition; video metadata (human, vehicle, non-motor vehicle); IVS; license plate comparison; tripwire people counting; regional people counting; abnormal number of people in queue; smoking detection; call detection; face & body detection |
| AI by Recorder | Face detection; face recognition; video metadata (human, vehicle, non-motor vehicle); IVS |
| AcuPick | 1. AI by Recorder: Supports 8-channel 2 MP or 4-channel 4 MP resolution; 2. AI by Camera: Supports 12-channel 2 MP or 6-channel 4 MP resolution |
| Face Detection | 1. AI by Recorder: supports 8-channel 2 MP or 4-channel 4 MP resolution; 2. AI by Camera: supports 12-channel 2 MP or 6-channel 4 MP resolution; 3. Supports 6 properties: Gender, age, glasses, expression, face mask, and beard |
| Face Database Capacity | 1. 100 human face databases with 300,000 face pictures in total; 2. 5 passerby databases with 300,000 face pictures in total; The human face database and the passerby database share the total capacity and number of face images |
| Face Recognition | 1. AI by Recorder: 8-channel 2 MP or 4-channel 4 MP with normal IP camera; 12-channel 2 MP or 6-channel 4 MP with face detection IP camera (Totally 12 × 2 MP or 6 × 4 MP face pictures analyzed per second); 2. AI by Camera: 16-channel 2 MP or 16-channel 4 MP with face recognition IP camera; 3. Supports entries frequency alarm |
| Search by Image | Search by image in the face database, search by face or human body images, and 1:1 face recognition |
| License Plate Database Capacity | 1. 50 plate databases with 300,000 plate numbers in total; 2. Supports allowlist and blocklist |
| Vehicle License Plate Comparison | Supports 12-channel 2 MP or 6-channel 4 MP resolution with ITC |
| Video Diagnosis | 1. Supports 1-channel tour detection; 2. Supports 12 detection items: blurry video; low contrast; video tampering; video jitter; image freeze; overexposure detection; video loss; noise detection; scene changing; static noise; interference fringe and color cast |
| Industrial Algorithms | The industrial algorithm is an optional installment |
| PPE Detection | 1. AI by Recorder: 4-channel 2 MP/4 MP or 2-channel 8MP; 2. Rules: AI by Recorder: hat/safety helmet detection, Balaclava, workwear detection (detect by color attributes or registered database), face mask detection, goggles detection, seatbelt detection, safety vest detection, shoes detection, gloves detection, mask detection, exposed hair detection and arm band detection |
| Access Channel | 16-channel |
| Network Bandwidth | Incoming bandwidth: 96 Mbps Recording bandwidth: 96 Mbps Outgoing bandwidth: 96 Mbps |
| Résolutions | 16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p |
| Capacité de décodage | 1-channel 16 MP; 1-channel 12 MP@20 fps; 1-channel 12 MP@15 fps; 2-channel 8 MP@30 fps; 2-channel 8 MP@15 fps; 3-channel 6 MP@30 fps; 3-channel 5 MP@30 fps; 3-channel 5 MP@25 fps; 4-channel 4 MP@30 fps; 6-channel 3 MP@25 fps; 4-channel 1080p@60 fps; 9-channel 1080p@30 fps; 16-channel 720p@30 fps |
| Video Output | 1-channel VGA output; 1-channel HDMI output; VGA 1/HDMI 1 outputs the same video source |
| Multi-screen Display | Max. 16-channel local live view; Max. 16-channel PCAPP live view |
| Third-party Camera Access | ONVIF;RTSP;Sony;Panasonic;Axis;Arecont;Pelco;Canon;Samsung |
| Compression vidéo | Smart H.265+;H.265;Smart H.264+;H.264 |
| Compression audio | G.711a;G.711u;PCM;G.726 |
| Protocoles réseau | HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;P2P;IPv6;UPnP;SNMP |
| Mobile Phone Access | DMSS |
| Interopérabilité | CGI;SDK;ONVIF (Profile S & Profile G & Profile T) |
| Navigateur | Chrome; PCAPP; IE9 or higher; Firefox |
| Network Mode | Multi-address mode;Load balance;Fault-tolerance;Link aggregation |
| Multi-channel Playback | 16 channels |
| Record Mode | Video detection;AI event;Thermal;All Video;Instant record;External alarm;Smart motion detection |
| Storage Method | Local hard disk |
| Backup Method | Hard disk;External USB storage device |
| Playback Function | 1. Play; Pause; Stop; Fast forward; Fast backward; Reverse play; Frame by frame; 2. Full-screen; Backup (clip and file); Snapshot; Digital zoom; Audio on and off |
| Record Management | Supports record control (continuous, event-based, scheduled, scheduled & event-based) |
| General Alarm | Motion detection;Video tampering;Local alarm;IPC external alarm;Fire alarm;Temperature alarm;Temperature contrast alarm;Hot spot alarm;Cold spot alarm |
| Anomaly Alarm | IPC offline alarm; storage error; HDD full; IP conflict; MAC conflict; login lock; AI module temperature alarm; AI module offline; fan malfunction; no HDD; power exception |
| Alarm Linkage | Record; snapshot (full image); alarm uploading; remote device alarm output; camera audio; buzzer; log; preset; email; smart tracking. Disarming alarm linkage action by period or one-click sync disarm config with channels |
| Entrée audio | 1 channel |
| Sortie audio | 1 channel |
| Entrée d'alarme | 4 channels |
| Sortie d'alarme | 2 channels |
| Disk Interface | 1 slot, SATA. Max.20 TB/HDD |
| RS-232 | 1 port |
| RS-485 | 1 port |
| USB | 2 × rear-mounted USB 3.0 ports;2 × front-mounted USB 2.0 ports |
| HDMI | 1 port |
| VGA | 1 |
| Port réseau | 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet ports |
| Power | Single supply |
| Disk Bay | 1 |
| Form Factor | 1U |
| Alimentation | 12 VDC, 5 A |
| Consommation | 12 W (without HDD, idling); 19 W (all HDDs connected) |
| Fan | Intelligent speed controlling fan |
| Poids net | 1.75 kg (3.86 lb) |
| Poids brut | 2.78 kg (6.13 lb) |
| Dimensions | Chassis: 304 mm × 223.8 mm × 43.5 mm (11.97" × 8.11" × 1.71") (W × D × H) |
| Packaging Dimensions | With packaging: 399 mm × 304 mm × 133 mm (15.71" × 11.97" × 23.58") (W × D × H) |
| Température de fonctionnement | –10 °C to +55 °C (+14 °F to +131 °F) |
| Humidité de fonctionnement | 10%–90% (RH), non-condensing |
| Operating Altitude | ≤5,000 m (16,404.20 ft) |
| Installation | Desktop;Rack |
| Certifications | CE-LVD: EN 62368-1; CE-EMC: EN IEC 61000-3-2, EN 61000-3-3, EN 55032, EN 50130-4, EN 55035 |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : IVD3116-1I · Marque : Dahua
