Description et caractéristiques
Tourelle IP
- 4 MP
- VF motorisée 2.7-12 mm
- Deep Learning
- Lecture de plaque
- Métadonnées véhicule (type/ marque/ couleur)
- Sortie audio
- RS-485
- IP54
- 12V
Caractéristiques principales
- Technologie de caméra : Caméra IP
- Intelligence Artificielle : Lecture de plaque
- Résolution : 4 MP
- Varifocale : 2.7 - 12 mm
- Compensation contre jour : WDR 140dB
Fiche technique
| Capteur | 1/1.8" CMOS |
|---|---|
| Image Resolution | 2688 × 1520 |
| Obturateur électronique | Auto/Manual 1/25s~1/10,000s |
| Max. Detection Speed | 20 km/h |
| Sensibilité (éclairement min.) | 0.001 Lux@F1.8 (Color, 30 IRE) 0.0002 Lux@F1.8 (B/W, 30 IRE) 0 Lux (Illuminator on) |
| ROM | 1 GB |
| RAM | 4 GB |
| Rapport signal/bruit | >56 dB |
| Balayage | Progressive scanning |
| Focale | 2.7 mm–12 mm |
| Champ de vision | H: 115° (W)–47° (T) V: 62° (W)–27° (T) D: 137° (W)–54° (T) |
| Focus Control | Auto, area focus, manual |
| Number of Lens | 1 |
| Type d'objectif | Motorized Vari-focal |
| Ouverture max. | 1.8 |
| Iris | DC-Iris |
| Distance DORI | Identify |
| W | 5.8 m (19.03 ft) |
| T | 13.1 m (42.98 ft) |
| Nombre d'illuminateurs | 3 (above) + 16 (below), IR |
| Contrôle de l'éclairage | Auto; manual |
| Illuminator Type | IR |
| Portée de l'éclairage | ANPR: 10 m (32.81 ft) Video monitoring: 20 m (65.62 ft) |
| Éclairage intelligent | According to the brightness of the environment, the camera automatically adjusts the intensity of its light to reveal the details of moving targets. |
| Infrared Wavelength | 850 nm |
| Video Resolution | Main stream: 4M (2688 × 1520)/1080p (1920 × 1080)/720p (1280 × 720) Sub stream: 720p (1280 × 720)/960H (960 × 576, 960 × 480)/D1 (704 × 576, 704 × 480)/CIF (352 × 288, 352 × 240) |
| Stream | PAL: Main stream (2688 × 1520@25 fps, 1920 × 1080@25 fps, 1280 × 720@25 fps), sub stream (1280 × 720@25 fps, 960 × 576@25 fps, 704 × 576@25 fps, 352 × 288@25 fps); NTSC: Main stream (2688 × 1520@30 fps, 1920 × 1080@30 fps, 1280 × 720@30 fps), sub stream (1280 × 720@30 fps, 960 × 480@30 fps, 704 × 408@30 fps, 352 × 240@30 fps) |
| Compression vidéo | H.264H; H.264B; H.264M by default; H.265; MJPEG; H.264M |
| Débit vidéo | H.264B: 2,179 kbps–13,074 kbps H.264M: 2,179 kbps–13,074 kbps H.264H: 2,179 kbps–13,074 kbps H.265: 2,179 kbps–13,074 kbps MJPEG: 6,537 kbps–39,223 kbps |
| Scene Self-adaptation (SSA) | Yes |
| Contrôle du gain | Manual; Auto |
| Réduction du bruit | 3D NR |
| Région d'intérêt (RoI) | Yes (3 ROI) |
| Image Tampering Prevention | Yes. Watermarks can be added to videos and images for verification. |
| Contrôle du débit | CBR; VBR |
| Stockage | Bult-in TF card port. Supports Kingston 16 G, 32 G, 64 G,128 G, 256 G; Dahua card 16 G, 32 G, 64 G, 128 G, 256 G; SanDisk 16 G, 32 G, 64 G, 128 G, 256 G |
| Restricted List/Trusted List | Allowlist: 110,000; Blocklist: 110,000 |
| Basic Event | Alarms for events of defocus, no storage card, storage card no space, storage card error, network disconnection, IP conflict, and illegal access. |
| Alarm Linkage | Upload to FTP/Memory card, notify monitoring center, send e-mail, and trigger alert output and snapshot. |
| Automatic Network Replenishment (ANR) | Yes, platform/FTP |
| Capture Distance | 2.5 m–6 m (8.20 ft–19.69 ft) |
| Detected Width | 3 m–4 m (9.84 ft–13.12 ft) |
| Protocoles réseau | HTTP; Https; 802.1×; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; NTP; SFTP; DDNS; SNMP; PPPoE |
| API | Yes |
| SDK | Yes |
| Interopérabilité | ONVIF (Profile S/Profile T/Profile M); CGI; ITSAPI; P2P |
| Logiciels de gestion | DSS Pro |
| Sécurité | Username and password; MAC address; HTTPS; IEEE 802.1×; network access control |
| Navigateur | Plug in: IE 9, 10, 11. Chrome 52 and earlier versions Firefox 42 and earlier versions No plug in: Chrome 92 and later versions |
| Image Encoding Format | JPEG |
| Image Setting | Brightness; contrast; saturation; gamma; sharpness; gain; white balance |
| Jour/Nuit | IR filter, support three modes: color/B/W/auto |
| WDR | 140 dB |
| HLC | Yes |
| BLC | Yes |
| Balance des blancs | Auto;Regional Custom;Manual;Outdoor;Natural;Street Lamp |
| Digital Detail Enhancement (DDE) | Yes |
| OSD Overlay | Supports overlay of time; address (position of channel), lane (number/direction), plate (number and color), vehicle (color, type) |
| Audio Port | Yes |
| Sortie audio | 1 channel (RCA port) |
| Port réseau | RJ-45 (10/100 Mbps Ethernet port) |
| Entrée d'alarme | 2, optocoupler input (wet node on-off value: 5 V) |
| Sortie d'alarme | 2, relay output (2A 30 VDC/0.5 A 125 VAC), which can connect to devices such as barriers |
| RS-485 | 1 Channel (half duplex, transparent, DHRS, com port push) |
| Reset Button | Yes |
| Wiegand | 1 Channel, SHA-1 26 bit |
| Maximum Number of Passed Vehicles | 10,000 |
| Max. Number of Connections | 10 |
| AI Recognition | Recognizes vehicle types, vehicle signs, vehicle color, vehicle plate, plate, vehicle without plate. |
| Video Metadata | Displays the intelligent frame, plate and vehicle paths. |
| Vehicle Brand | Recognizes 147 vehicle logos. |
| Vehicle Color | Recognizes 12 colors: Grey, black, white, silver, blue, green, purple, red, orange, pink, brown, and yellow. |
| Vehicle Type Recognition | Recognizes 9 vehicle types: Large Bus, Heavy Truck, Medium Truck, Sedan, Van, Light Truck, Medium Bus, SUV, MPV, Pickup |
| Capture Rate | In the recommended installation and lighting condition, the vehicle capture rate ≥ 99% |
| Recognition Rate | In the recommended installation and lighting condition, the recognition rate for positive and departing vehicles≥ 96%; the recognition rate for European vehicle plates ≥ 98% |
| Alimentation | 12 VDC, 3 A |
| Consommation | No lighting <6 W Lighting <28 W |
| Indice de protection | IP54 |
| Material | Metal plate + glass |
| Dimensions | 254.0 mm × 221.0 mm × 711.0 mm (10" × 8.70" × 27.99") |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : ITC416-PL8I-IZ · Marque : Dahua
