Description et caractéristiques
Caméra cube HDCVI blanc
- 2 Mp
- FF 2.8 MM
- IR 20m
- Starlight
- Micro
Caractéristiques principales
- Technologie de caméra : Caméra HDCVI
- Fonctionnalités de la caméra : Starlight
- Résolution : 2 MP
- Focale Fixe : 2.8 mm
- IR & LED : IR 20 m
Fiche technique
| Capteur | 1/2.8" CMOS |
|---|---|
| Effective Pixels | 1920(H)×1080(V), 2MP |
| Balayage | Progressive |
| Obturateur électronique | PAL: 1/4s~1/100,000s NTSC: 1/3s~1/100,000s |
| Minimum Illumination | 0.004Lux/F1.6, 30IRE, 0Lux IR on |
| Rapport signal/bruit | More than 65dB |
| IR Distance | Up to 20m (66feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 1 |
| Type d'objectif | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focale | 2.8mm (3.6mm Optional) |
| Max Aperture | F1.6 |
| Angle of View | H: 110° (86.9°) V: 60° (46.3°) |
| Focus Control | N/A |
| Distance mini de mise au point | 500mm(1200mm) 19.7''(47.2'') |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
| Résolutions | 1080P (1920×1080) |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P |
| Video Output | 1-channel BNC high definition video output / CVBS video output (DIP switch) |
| Jour/Nuit | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 120dB |
| Contrôle du gain | AGC |
| Réduction du bruit | 2D/3D |
| Balance des blancs | Auto / Manual |
| Smart IR | Auto / Manual |
| Detection | Passive infrared |
| Detection Range | Max. 15m, 110° |
| Alarm prompt | Whitelight & Siren |
| Installation height | Defualt bracket, wall mount, 2.2-2.5m |
| Fréquence radio | 433/868/915Mhz |
| Wireless Protocol | Airfly |
| Device Connection | Up to 32 wireless devices connection |
| Wireless Transmission Distance | Up to 100m (open space/ no interference) |
| Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Audio Interface | Built-in mic & 1 ch audio in interface |
| Alarm Interface | 1 ch alarm out interface |
| Alimentation | 12V DC ±30% |
| Consommation | Max 5.5W (12V DC, IR on) |
| Operating Conditions | -20°C ~ +60°C (-4°F ~ +140°F) / Less than 95% RH * Start up should be done at above -20°C (-4°F) |
| Storage Conditions | -20°C ~ +60°C (-4°F ~ +140°F) / Less than 95% RH |
| Ingress Protection &Vandal Resistance | IP67 |
| Casing | Plastic (Body) + Aluminium (Bracket) |
| Dimensions | 144.7mm×76.7mm×146.4mm (5.70"×3.02"×5.76") |
| Poids net | 0.41kg (0.90lb) |
| Poids brut | 0.55kg (1.21lb) |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : HAC-ME2241CP-W-0280B · Marque : Dahua
