Description et caractéristiques
Tourelle IP
- 2688×1520
- FF 4 mm IR 850 nm
- Lecture de plaque
- Détection véhicules
- Sortie relais barrières
- Déclencheurs multiples
- IP54
- 24V
Caractéristiques principales
- Technologie de caméra : Caméra IP
- Intelligence Artificielle : Lecture de plaque
- Résolution : 4 MP
- Focale Fixe : 4 mm
- Alimentation de la caméra : 24 V
Fiche technique
| Type d'objectif | 4mm |
|---|---|
| Aperture | F1.6 |
| Focal Length and FoV | 4 mm, horizontal FoV: 79°, vertical FoV: 43.3°, diagonal FoV: 92° |
| Monture | M16 |
| lris Type | Fixed |
| Supplement Light Type | IR Light |
| Supplement Light Range | 850nm |
| Trigger Type | Video Detection, I/O Coil, Radar Mixed Traffic |
| Picture Type | Scene Picture, Scene Picture + Close-up Picture |
| Scene Mode | Entrance and Exit Toll Gate, Underground Parking Entrance and Exit |
| Capture Type | Strobe Light Mode |
| Image Format | JPEG |
| Capture Resolution | 2688 × 1520 |
| License Plate Recognition | Forward, Backward, Bidirection |
| LED Control | Supports automatic light control/time control of LEDs |
| Smart Recognition | ANPR |
| Capture Picture Overlay | Location, Capture Time, Plate Number, Capture No., Vehicle Color Vehicle Type |
| Main Stream | 50 Hz: 50 fps (2688 × 1520(Default), 1920 × 1080, 1280 × 720) 60 Hz: 60 fps (2688 × 1520(Default), 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 50 fps (1920 × 1080(Default), 1280 × 720, 704 × 576) 60 Hz: 60 fps (1920 × 1080(Default), 1280 × 720, 704 × 576) |
| Third Stream | 50 Hz: 50 fps (1280 × 720(Default), 704 × 576) 60 Hz: 60 fps (1280 × 720(Default), 704 × 576) |
| Image Settings | Saturation: 0 to 100 Brightness: 0 to 100 Contrast: 0 to 100 Gain: 0 to 100 3D DNR: Off, Normal, and Expert modes are selectable. White balance: White Balance 1 and White Balance 2 are selectable. |
| Frame Rate | 50 fps (P)/60 fps (N) |
| Barrier Gate Control Mode | By Camera/Platform/Mixed |
| Keep Boom Pole Open for Following Vehicle | Enable/Disable |
| Lock Barrier Gate for Large-Sized Vehicle | Yes |
| Barrier Gate Status | None, Barrier Gate Close In Place, Barrier Gate Open In Place, Remote Control Barrier Gate |
| Allowlist and Blocklist | Up to 100,000 allowlist and blocklist totally |
| ROI | 8 regions respectively for main stream and sub-stream, 6 levels for each region. |
| Compression vidéo | Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, |
| H.264 Type | Low profile Medium profile High Profile |
| Débit vidéo | 32 Kbps to 16 Mbps |
| Bit Rate Type | Constant, Variable |
| Scalable Video Coding (SVC) | H.265 encoding |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP Upload Picture, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, IPv6, UDP, SSL/TLS,SRTP |
| API | Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP, Otap, Guarding Vision Platform |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
| Sécurité | Password protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Résolution max. | 2688 × 1520 |
| Sensor Type | 1/1.8" Progressive Scan GMOS（Global shutter CMOS） |
| Sensibilité (éclairement min.) | Color: 0.0005 Lux @ (F1.2, AGC ON) B/W: 0.0001 Lux @ (F1.2, AGC ON) 0 Lux with IR |
| Shutter | 1/30 s to 1/100,000 s |
| Day/Night Switch | Supported |
| IR Cut Filter | IR cut filter Blue glass module to reduce ghost phenomenon |
| Trigger Input | 3-ch triggered inputs |
| Trigger Output | 2-ch alarm output |
| Wiegand | 1-ch, Supported: CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit |
| Entrée d'alarme | 4-ch |
| RS-485 | 1-ch |
| RS-232 | 1-ch |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Memory Card Slot | 1 TF card slot, up to 1TB |
| Relay Output | 4-ch |
| Power Output | 12VDC, max.1A |
| LPR Accuracy | Accuracy (Under recommended installation and lighting conditions): License plate recognition rate ≥98.5% Capture rate ≥99% Driving direction accuracy rate ≥98% |
| Valid Distance | 1.5 to 12m |
| Alimentation | 24VDC |
| Consommation | 72W Max. |
| Package Dimensions | 465 mm × 200 mm × 198 mm (18.31 × 7.87 × 7.80 inch) |
| Dimensions | 195 × 150 × 673 mm (7.68 × 5.91 × 26.5 inch) |
| Storage Temperature and Humidity | Temperature: -30 °C to 70 °C (-4°F to 158 °F) Humidity: 95% (non-condensing) |
| Startup and Operating Conditions | Temperature: -30 °C to 65 °C (-22 °F to 149 °F) Humidity: 95% (non-condensing) |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| External Light Type | IR |
| External Light Distance | 3-8m, 0.032W/㎡ |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : DS-TMC403-EL/(G/Y) · Marque : Hikvision
