Description et caractéristiques
Écran Full HD
- 32 pouces
- VGA/HDMI
- Compatibilité VESA 100x100
Caractéristiques principales
- Type de produit : Écran
- Taille de l'écran : 32 pouces
- Résolution de l'écran : FULL HD (2K)
- Sorties vidéo de l'écran : Sortie VGA, Sortie HDMI
- Compatibilité VESA : VESA 100x100
Fiche technique
| Screen Size | 32 inch , 81.3 cm |
|---|---|
| Active Display Area | 698.4 (H) mm × 392.85 (V) mm, 27.44 dm² |
| Résolutions | 1920 × 1080 |
| Backlight | D-LED |
| Pixel Pitch | 0.12125 (H)mm x 0.36375 (V) mm |
| Brightness | 300 cd/m² |
| Viewing Angle | 178° (H) / 178° (V) |
| Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 |
| Response Time | 8 ms |
| Refresh Rate | Typ. 60 Hz，Max. 75 Hz |
| Haze | Haze 2 % |
| Reliability | 7 × 24 H |
| Color Gamut | 72 % NTSC |
| Video & Audio Input | VGA × 1，HDMI 1.4 × 1，Audio Output × 1 |
| Video & Audio Output | Speaker(8Ω 10W) × 2 |
| Data Transmission Interface | None |
| Control Interface | None |
| Alimentation | 100~240 VAC, 50/60 Hz |
| Consommation | ≤ 48 W |
| Standby Consumption | ≤ 0.5 W |
| Working Temperature | 0℃ to 40 ℃ (32 ℉ to 104 ℉) |
| Working Humidity | 20% to 90% RH (Non-Condensing) |
| Température de stockage | -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) |
| Humidité de stockage | 10% to 90% RH (Non-Condensing) |
| Matériau du boîtier | Plastic |
| VESA | 100 mm × 100 mm (4 - M6 × 10 mm) |
| Bezel Width | 16.7 mm (top/left/right), 20.5 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 735.08 (W) mm × 489.16 (H) mm × 207.95 (D) mmWithout base: 735.08 (W) mm × 433.46 (H) mm × 80.19 (D) mm |
| Package Dimensions (W × H × D) | 808 (W) mm × 510 (H) mm × 140 (D) mm |
| Standby Time | 600s |
| Poids net | 4.55 ± 0.5 kg |
| Poids brut | 6.1 kg ± 0.5 kg |
| Packing List | Monitor × 1, Base component × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1，remote control × 1 , Base screw × 6，Wall-mount screw × 4 |
| Remarks | The base is included by default. The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : DS-D5032F3-1V0S · Marque : Hikvision
