Description et caractéristiques
Détecteur Volumétrique Radio Bidirectionnel
- Double technologie
- Anti-animaux
- Détection sur 12M et 90° d'ouverture
Caractéristiques principales
- Type de périphérique : Détecteur de mouvement
- Zone de couverture - mouvement : Distance 12m / Angle 90°
- Type de raccordement : Raccordement radio
- Technologie du détecteur : Infrarouge, Immunité des animaux
- Communication : Bidirectionnelle
Fiche technique
| Indicator Light | 1 × green alarm indicator |
|---|---|
| Button | 1 × power button |
| Tamper Alarm | Yes |
| Remote Update | Cloud update |
| Search | Signal strength detection |
| Low Battery Alarm | Yes |
| Carrier Frequency | 868.0 MHz–868.6 MHz |
| Transmitter Power (EIRP) | Limit 25 mW |
| Communication Distance | Up to 1,600 m (5,249.34 ft) in an open space |
| Communication Mechanism | Two-way |
| Encryption Mode | AES128 |
| Frequency Hopping | Yes |
| Alimentation | CR123A battery |
| Battery Life | 4 years |
| Consommation | Max. 120 mW |
| Operating Environment | –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
| Humidité de fonctionnement | 10%–90% (RH) |
| Dimensions | 104.0 mm × 60.0 mm × 50.0 mm (4.09" × 2.36" × 1.97") (L × W × H) |
| Installation | Wall mount |
| Poids net | 100 g (0.22 lb) |
| Poids brut | 170 g (0.37 lb) |
| Matériau du boîtier | PC + ABS |
| Certifications | CE; EN 50131-1:2006+A1:2009+A2:2017+A3:2020; EN 50131-2-2:2017; EN 50131-6:2017; EN 50131-5-3:2017; Security Grade 2; Environmental Class II |
| Packaging Dimensions | 135.0 mm × 98.5 mm × 56.8 mm (5.31" × 3.88" × 2.24") (L × W × H) |
| Measuring Range (Temperature) | –15 °C to +65 °C (+5 °F to +149 °F) (indoor) |
| Measuring Precision (Temperature) | ± 1 °C (± 1.8 °F) |
| Resolution (Temperature) | 1 °C (33.8 °F) |
| Detection Mode | PIR |
| Sensor | Dual elements low-noise PIR sensor |
| Test Mode | Yes |
| Detection Range | 12 m (39.37 ft) (90°) with installation height of 2.2 m (7.21 ft) |
| Detection Speed | 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s) |
| Pet Immunity Level | ≤ 18 kg (39.68 lb) |
| White Light Resistance Level | 2000 lx |
| Two-way Digital Temperature Compensation | Yes |
| Sensitivity | 3 levels adjustable |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : ARD1233-W2(868) · Marque : Dahua
