Description et caractéristiques
Contrôleur d'accès sans fil
Caractéristiques principales
- Type de switch : Switch Non manageable, Switch Non-POE
- Nombre de ports du switch : 5 ports
- Type de produit : Switch
Fiche technique
| Model | DH-PFM888-AC |
|---|---|
| Hardware | · CPU: Intel Celeron J1900 Quad-Core Processer 2.4GHz · Memory: DDR3 8GB · Memory of CF card: 4GB · Internfaces: 10/100/1000M Base-TX *6 USB *2 Console *1 · Dimension: 430 ×300 ×44.5(mm )(1U ) · Power: AC 220V (75W) · Working Temperature: 0°C~50°C · Weight: 3.37kg |
| Performance | · Support up to 2048 access points · Support up to 65535 clients · Support up to 1024 templates |
| Access Control | · Portal, Radius · It's allowed only one user to log into the web management interface at the same time. If a new user logs into the web management interface,then the logged-in user will be logged out. |
| Statistics | · Platform: Device name, Firmware Version, IP address, CPU Usage, Memory Usage, Run Time, System Time · Device ( Access Points): Total Units, Online Units, Offline Units · Terminal: Total Units, Online Units, Offline Units · Alarm |
| Device/Terminal Management | · Device: Status: Online, Offline, Unmanaged, Upgrading, Configurating, Failed to upgrade, Failed to configure, etc Device Name, Model, IP Address, MAC address, Firmware Version, Run Time, Template,Location, etc Wireless: Channel, Channel Width, Output Power, Maximum Transmission Rate, SSID, Encryption Method, TDMA |
| Template Management | · Display current templates which have been saved · Template classification by device type · New or edit template, including following: Region, Channel, Channel Width, Output Power Setting, Multi-VAP, SSID, Hidden SSID Broadcast, Client Isolation, TDMA, Max User Limitation, Authentication/Encryption Method, Auto-match |
| Image Management | · Display Image Name, Version, File Size, Update Time · Support upload and storage image to device · Support Auto-upgrade · Support Batch-upgrade |
| Configuration | · Support save configuration to local PC · Support import configuration |
| Log Management | Log Classification, log export, log upload, log search |
| Network and Security | · Management Protocol: CAPWAP · Discovery Method: DHCP (Option43), Static IP, Broadcast · VLAN · DoS Protection |
| Upgrade | · Support upgrade via web · Service Interruption time via upgrade ≤ 7 minutes |
📄 Télécharger la fiche technique (PDF)
Référence fabricant : PFM888-AC · Marque : Dahua
